Tool attachment TA960-1

  • Modular design
  • External signals
  • Wide range of media modules – simple to customize
  • Designed to meet bodyshop application demands
Art.no: P7902A Categories: , ,
Tool changing ability

The RSP tool changers are designed to maximize the flexibility and reliability of your robot fleet. They offer the possibility to enhance your robot application by allowing it to switch between different tools, such as grippers, weld units, fixtures etc. Tool changers from RSP are robust and can manage continuous changing operations with maintained reliability and safety. Depending on model and options, electrical signals, weld and servo power, data, water, and compressed air can be transferred from the robot side to the tool.

All our tool changers feature the patented locking device, TrueConnect™. It reduces play to the minimum and enables absolute alignment repeatability throughout its lifespan. With its unique design, it does not require exact alignment before docking with different tools.

Air channels available to tool

1, Additional channels can be added with external media module

Air connection, outlet

G 1/2"

Air flow per channel

2000 l/min | 70.6 CFM

Max air pressure

10 bar | 145 psi

Air quality

Oil-clean and waterless filtered air, with max 25µm particle content

IP Class

IP 54

Working temperature

+10°C – +50°C | 50 °F – 120 °F

Modules


Electrical modules

Air/Water modules
